Airmar CM510C-L-NC
Home / Equipment catalogue / Fishfinders & Sonar / Airmar CM510C-L-NC
Airmar · Code CM510L-93-01
Transducers · Depth measurement, CHIRP
Fishfinders & Sonar
Discover the product
Airmar sensor CM510C-L-NC for connection to a compatible fishfinder or sonar. Supports depth measurement with CHIRP. This version has a power rating of 3 kW, low band 25-50 kHz. Version selection details: display connection: no connector, cable length 25 m (82').
Connections & accessories
No documented connection has yet been recorded for this exact part number. This does not mean it is incompatible.
Functions & interfaces
Depth measurement · CHIRP
Technical specifications
Equipment type
Depth transducers
Measurements
Depth
Transducer power
3 kW
Low frequency
25-50 kHz
Frequency technology
CHIRP-Ready Single-Band
Mounting
Tank, Cavity, Pocket/Keel Mount
Housing
Urethane
Display connection
No Connector
Cable length
25 m (82')
Hull material
Any hull material with external wet box or constructed pocket
Maximum depth under suitable conditions
3,048 m (10,000')
Version confirmation
Before you choose, we will confirm the exact part number and current version with you.
Browse the equipment
Kit contents, interfaces and required accessories are checked for the exact part number. Connection to another system does not mean all functions are built in.
Is it right for your vessel?
Tell us about your vessel, existing equipment and requirements. Elmare will help you choose the right configuration.
Request information by email ↗
+30 210 400 2538
Elmare · 1 Proussis Street, Keratsini
