Raymarine YachtSense Signal Module · 4 I/O channels · up to 250 mA per output
Home / Equipment catalogue / Instruments & Networks / Raymarine YachtSense Signal Module · 4 I/O channels · up to 250 mA per output
Raymarine · Code E70597
4 digital / analogue channels · up to 250 mA per output · YachtSense
Instruments & Networks · Energy & Electrical
YachtSense Signal E70597 — right-hand side view.
Image: Raymarine
Discover the product
The Raymarine YachtSense Signal Module E70597 provides four digital or analogue input / output channels. Each channel can serve as a low-current output up to 250 mA, with a total limit of 1 A.
It connects switches and level, temperature or voltage sensors to the YachtSense system. It also supports 4–20 mA sensor signals and relay control. Integration uses the internal connection between YachtSense modules.
Connections & accessories
No documented connection has yet been recorded for this exact part number. This does not mean it is incompatible.
Functions & interfaces
Digital load management
Technical specifications
Equipment type
Instruments & Sensors
Channels
4 digital / analogue inputs or outputs
Current output
Up to 250 mA per channel · 1 A total
Sensor signals
Digital, resistance, voltage and 4–20 mA
Nominal power supply
12 / 24 V DC
Module communication
Internal connection 6 pins
More images
YachtSense Signal E70597 — front view. ↗
Image: Raymarine
Selection & compatibility
This model is included in our catalogue. The exact configuration, compatibility and supply availability are confirmed when you contact us.
Browse the equipment
Kit contents, interfaces and required accessories are checked for the exact part number. Connection to another system does not mean all functions are built in.
Is it right for your vessel?
Tell us about your vessel, existing equipment and requirements. Elmare will help you choose the right configuration.
